Windproof Brake
Jiaozuo Hongfa Windproof Brake YDGZ (direct acting) hydrauli
Jiaozuo Hongfa Windproof Brake YDGZ (direct acting) hydraulic top rail brakes
YDGZ (direct acting) hydraulic top rail brakes
Overview: YDGZ series of hydraulic top rail brakes are mainly used for rail-type large and medium-sized cranes and ports, terminals and other loading and unloading machinery work and non-working state of the wind brake, mechanical locking and so on.
Conditions of use:
Ambient temperature: 0 ℃ -40 ℃.
The surrounding work environment shall not have flammable, explosive and corrosive gases, air relative humidity of not more than 90%.
The altitude of the use site is in accordance with GB755-2000
YDGZ (direct acting) hydraulic top rail brakes
Overview: YDGZ series of hydraulic top rail brakes are mainly used for rail-type large and medium-sized cranes and ports, terminals and other loading and unloading machinery work and non-working state of the wind brake, mechanical locking and so on.
Conditions of use:
Ambient temperature: 0 ℃ -40 ℃.
The surrounding work environment shall not have flammable, explosive and corrosive gases, air relative humidity of not more than 90%.
The altitude of the use site is in accordance with GB755-2000
Unit: (mm)
|
model |
Rated top rail force (KN) |
Rated static friction resistance (KN) |
Cylinder working pressure (MPa) |
Open gate oil (L) |
Effective travel |
Installation height L1 |
L2 |
L3 |
L4 |
D1 |
D2 |
D3 |
D |
Weight (kg) |
|
YDGZ-20 |
196 |
88 |
5 |
1 |
16 |
506 |
491 |
69 |
25 |
335 |
375 |
425 |
twenty two |
350 |
|
YDGZ-35 |
343 |
154 |
7 |
1.4 |
625 |
610 |
85 |
33 |
400 |
455 |
520 |
27 |
460 |
|
|
YDGZ-45 |
441 |
198 |
10 |
1.4 |
480 |
|||||||||
|
YDGZ-50 |
500 |
225 |
11 |
1.4 |
626 |
611 |
85 |
34 |
400 |
455 |
520 |
27 |
500 |
