Jiaozuo Hongfa DJPZ series of motor disc brakes
DJPZ series of motor disc brakes
Overview: DJPZ motor disc brake is an important component of the electrical drive system, which together with the Y series of motors to form a new type of YEJ series of electromagnetic brake three-phase asynchronous motor. Mainly used in metallurgy, chemical industry, construction, mining machinery and other industries, to achieve rapid parking and accurate positioning of the body for safety braking. The brake has the advantages of compact structure, easy installation, low noise, high sensitivity and reliable braking.
Conditions of use:
altitude of not more than 2000 meters.
The surrounding medium is not enough to corrode the metal, destroying the insulated gas and dust. The ambient air humidity is less than 90%.
When installed, there is no oil and dust in the friction plate and friction plate and brake.
Series brake coil Insulation class: Class B.
Power supply 380V, 50Hz, work for S1 or S3
Technical Parameters
|
YEJ motor |
model |
Rated torque Nm |
Rated power (20 ° C) w |
Turn-on time t1 (s) |
Off time t2 (s) |
Excitation voltage DC (V) |
|
|
Frame number |
Rated power Kw |
||||||
|
90 |
1.1 ~ 2_2 |
DJPZ114-18 |
18 |
60 |
0.12 |
0.11 |
99 |
|
100 |
1.5-3 |
DJPZ133-30 |
30 |
80 |
0.14 |
0.12 |
|
|
112 |
2.2-4 |
DJPZ150-40 |
40 |
110 |
0.16 |
0.15 |
170 |
|
132 |
2.2 ~ 7.5 |
DJPZ170-80 |
80 |
130 |
0.17 |
0.15 |
|
|
160 |
4 ~ 18.5 |
DJPZ202-160 |
160 |
150 |
0.22 |
0.21 |
|
|
180 |
11 ~ 22 |
DJPZ244-230 |
230 |
150 |
0.25 |
0.23 |
|
|
200 |
15 ~ 37 |
DJPZ280-400 |
400 |
200 |
0.33 |
0.31 |
|
|
225 |
22 ~ 35 |
DJPZ300-530 |
530 |
200 |
0.37 |
0.35 |
|
Note: When the coil power is 20 ° C, 10% difference is allowed with the selected input voltage.
Dimensions
Unit: (mm)
|
size
|
A |
B |
C |
D |
E |
F |
G |
H |
S |
Smax |
Weight kg |
|
DJPZ114-18 |
126 |
114 |
24.8 |
3XM6 |
25 |
28.1 |
8 |
59 |
0.4 |
1.0 |
4.7 |
|
DJPZ133-30 |
145 |
133 |
29.5 |
3XM6 |
30 |
32.8 |
8 |
60 |
0.4 |
5.4 |
|
|
DJPZ150-40 |
165 |
150 |
29.5 |
3XM8 |
30 |
32.8 |
8 |
62 |
0.5 |
7.8 |
|
|
DJPZ170-80 |
188 |
170 |
39.5 |
3XM8 |
30 |
42.8 |
12 |
75 |
0.5 |
1.2 |
9.8 |
|
DJPZ202-160 |
220 |
202 |
44.5 |
4XM10 |
35 |
47.8 |
12 |
90 |
0.6 |
16 |
|
|
DJPZ244-230 |
265 |
244 |
49 |
4XM10 |
40 |
52.8 |
14 |
108 |
0.6 |
22.7 |
|
|
DJPZ280-400 |
310 |
280 |
59 |
4XM12 |
50 |
63.4 |
18 |
117 |
0.8 |
1.5 |
36 |
|
DJPZ300-530 |
330 |
300 |
65 |
4XM12 |
55 |
69.4 |
18 |
127 |
0.8 |
42 |
